YG10 YG15 Tungsten carbide Wear Parts High Temperature Resistance strip wear parts

Home

YG10 YG15 Tungsten carbide Wear Parts High Temperature Resistance strip wear parts

Material:100%virgin raw material

Grade : YG10 YG15 YG25

Long lifetime by using wear parts

Application: cutting tools

Email：

info@cdcarbide.com

Feedback

YG10 YG15 Tungsten carbide Wear Parts High Temperature Resistance strip wear parts

Advantage of YG10 YG15 K30 Tungsten carbide strip bar non standard

1.Several times Long lifetime than steel strips bars

2.High hardness

3.High strength

4.High wear resistance

5.Anti corrosion and Anti High Temperature

6.It can be used as different shapes to suit your needs .(for wear resistance part,for cutting tools etc)

Grade of YG10 YG15 K30 Tungsten carbide strip bar non standard

Properties and applications of carbide strip
Grade	Density	T.R.S MPa	Hardness HRA	Performance & application recommended
CD6	14.9	2150	90	Good wear resistance, used for hard wood, used for processing original wood, aluminum section bar, brass rod and cast iron.
CD6A	14.9	1860	92	Has wear resistance higher than YG6, used for processing hard wood, original wood, aluminum section bar, brass rod and cast iron.
CD8	14.7	2320	89.5	Wear and percussion resistance , used for processing hard wood, soft wood, ferrous and non-ferrous.
CD2T	14.5	2350	92	Fine carbide, High wear resistance, high bending strength, high resistance to bonding, high thermal s trength. Machining of refractory alloys, stainless steel and high manganese steel, etc.
CD25	14.5	2150	92.2	Wear resistance and strength comparatively higher, suitable for processing cast iron, non-ferrous,metal and non-metallid materials.
CD10X	14.45	91.8	3000	Wear resistance and strength comparatively higher,suitable for maching cast iron,non-ferrous metal and non-metallid materials
Other grades of strips may be offered according to customers' requirement.

Application of YG10 YG15 K30 Tungsten carbide strip bar non standard

It can be used as cutters to cut cast iron, nonferrous metals, plastics, chemical fiber, stainless steel and high Manganese steel, etc.,and make drilling tools, mining tools, crushing tool, measuring gauges, wear parts, cylinder liners, precision bearings, nozzles and metal molds, etc..
1.Suitable for treating solid wood, shaving board and middle-density fiberboard.
2.Be used to make woodworking tools, such as forming tool, reamer, serrated knife blade and various blade.
3.suitable for machining hard wood, original wood as well as aluminum section bar, brass rod.
4,Mainly used as cutting tools for semi-automatic lathe, automatic lathe and planning machine.
5,Used as VSI rotor tips for stone crushing machine.
6,Applied as Plastic and tobacco cutters.

7,Widely used as Guide rail for centerless grinding machine.

8,Tungsten carbide strip is also suitable for the production of various types of motors, electronic progressive dies punches, etc.

K10 Cemented Tungsten Carbide Wear Flat Square Bar Strip cutting tools

All the products must be inspected strictly with the ultrasonic and only those haven't any harm such as pore can be shipped out. High density, high wear & impact resistance, which lead them a long lifetime.

All materials are tested in terms of hardness , density and T.R.S before using.

FAQ:

Q1 : Are you Factory or trading company ?
We are Factory with 12 years of production experience.

Q2: Where is your factory located ?
We are located in Zhuzhou city, Hunan province where is base of tungsten carbide .

Q3: Is the price Competitive?
We have our own Factory. Thanks to strong production and distribution system, we promise to offer our customers the most competitive price.

Q4: Are the products High Quality?
Yes. All products will be tested before bulk production, and we will check the physical properties, shape and tolerance for ensuring qualified products before shipping.
