YL10.2 K40UF K30 ground tungsten carbide rod bar

Home

YL10.2 K40UF K30 ground tungsten carbide rod bar

Dimension : can be customized or standard

ISO code grade: K01,k10,K20,k30,K40

Density: 12.75-15.3 G/cm3

TRS: 2800-3200N/mm2

Email：

info@cdcarbide.com

Feedback

YL10.2 K40UF K30 ground tungsten carbide rod bar

YL10.2 h6 ground tungsten carbide rod used as needles thimble

1. 100% virgin raw materials.

2. Various kinds of grades are availalbe based on customer's application.

3. we have professional advanced production line and inspeciton equipments to ensure high quality products.

4. Precision Ground and high polishing process

5. High wear resistance,high hardness and impact toughness

6. Advanced technology , precise grinding.

Product Name	Solid carbide rods blank and ground
Material	WC+CO
Grade	K05-K40
Grain Size	fine, medium
Hardness	87.6-94HRA
T.R.S	3000-4200
Surface	blank or ground
Application	Used for manufacturing cutting tools such as endmills, drills, reamers and dental burrs

Grade chart

Grade	ISO	Grain size	Cobalt Content (wt-%)	Density g/cm3	HARDNESS HRA	TRS (N/mm2)	APPLLICATION
K10UF	K05-K10	0.6	6.0	14.8	94	3800	Ultrafine grain size,with good wear resistant.higher wear resistant endmill and engraving tools are recommended.suitable for cutting PCB and plastic.
CD6	K10	1.0	6.0	14.95	92	3000	Drilk endmill and burr are recommended.Especially suitable for cutting non-ferrous metal and graphite(coating is needed).
K20UF	K20	0.7	8.0	14.6	92.5	3200	For cutting of the aluminum specially .
K40UF	K30	0.6	10	14.4	91.8	3000	Drill and endmill are recommended. Suitable for cutting stainless steek heat resistant alloy and cast iron.
CD15	K40	1.5	15	14	87.6	4000	Suitable for making punching of moulds、tools and anti -vibration boring bar etc.

Application

Solid cemented carbide rods(carbide rod bar/solid carbide rod price/carbide rod blanks can be used for making various drill bits, automobile special cutter, printed circuit board ,special cutters, engine special cutters, horology,processing special cutters, integral vertical milling cutter, graver and etc.

Besides , they can be used for making of cemented carbide stamping head, core bar and perforation tools.
The cemented carbide rods are used for cutting aluminum alloy , cast iron , stainless steel , refractory alloy steel ,nickel based alloy , titanium alloy and non ferrous metal , various carbide grades with stable properties have been widely recognized by worldwide tool makers. We can produced the ungrounded and grounded carbide rods.

Dimension

Without holes OD3-30*100/110/300/330mm h6 ground polished

YL10.2 Cemented carbide Tungsten carbide rods bars

Features of Cemented carbide rod
1. high strength and high hardness.
2. excellent hardness, wear-resistance, high elastic modulus, high flexural strength,
3. good chemical stability (acid, alkali, high temperature oxidation), impact resistance,
4. good toughness, low coefficient of expansion etc.

Grain size range: 1.2; 1.0; 0.8; 0.7; 0.6; 0.5; 0.4

Length range: 3mm--1400mm

Surface Roughness can be reached to: RA0.04.(reach a mirror effect surface after accurate grinding)

Diameter range: 0.1mm--60mm.

Diameter Grade: h5(H5), h6(H6), h7(H7), h8(H8), h9(H9).

All materials are tested in terms of hardness , density and T.R.S before using.

FAQ:

Q1 : Are you Factory or trading company ?
We are Factory with 12 years of production experience.

Q2: Where is your factory located ?
We are located in Zhuzhou city, Hunan province where is base of tungsten carbide .

Q3: Is the price Competitive?
We have our own Factory. Thanks to strong production and distribution system, we promise to offer our customers the most competitive price.

Q4: Are the products High Quality?
Yes. All products will be tested before bulk production, and we will check the physical properties, shape and tolerance for ensuring qualified products before shipping.
